Case
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
49 data points
Operating Specifications
| Operating Weight | 48,973 lb |
|---|---|
| Arm Breakout Force | 25,179 lb |
| Arm size | 386 in |
Engine
| Engine Model | Isuzu 4 HKIX |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 160.0 hp |
| Max Torque | 458 lb-ft |
| Engine Make | Isuzu |
| Stroke | 5 in |
| Bore | 5 in |
| Fuel Type | Requires ultra-low sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Hydraulic System
| Main pump - Maximum flow | 111.5 gal |
|---|---|
| System relief pressure | 4,975 psi |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Tail Swing Radius | 110 in |
| Overall Height | 119 in |
| Track Shoe Width | 32 in |
| Cab height | 118 in |
| Center to center - idler to sprocket | 145 in |
| Ground pressure | 5 psi |
| Boom length | 226 in |
| Minimum ground clearance | 109 in |
Transmission
| Max Speed | 3.5 mph |
|---|
Undercarriage
| Track Shoe Width | 32 in |
|---|
Brakes & Steering
| Service brake | SAHR disc - each motor |
|---|---|
| Brakes Type | Mechanical disc |
| Travel control | Dual stage relief or counter balance design |
Fluid Capacities
| Hydraulic system | 66.1 gal |
|---|---|
| Hydraulic Tank | 38.9 gal |
| Cooling system | 8.3 gal |
| Engine oil w/ filter change | 6.2 gal |
| Swing drive | 1.4 gal |
| Final Drive | 1.4 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 263 in |
|---|---|
| Max Reach Along Ground | 373 in |
| Max.Dumping Height | 269 in |
| Max Digging Reach on Ground | 384 in |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 3
| Overall height | 119 in |
|---|
Performance
| Lift over end Max. reach | 5,732 lb |
|---|---|
| Lift over side Max. reach | 4,894 lb |
| Lift over end 10' radius | 18,365 lb |
| Lift over side 10' radius | 18,365 lb |
