Case
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Operating Weight | 53,223 lb |
|---|---|
| Fuel Capacity | 70.0 gal |
| Hydraulic Pump Flow Capacity | 50.2 gal/min |
| Hydraulic System Fluid Capacity | 54.0 gal |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 6.8 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | AI-4HK1X Tier III certified |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 153.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 454 lb-ft |
Dimensions
| Ground Clearance | 216 in |
|---|---|
| Height - Top of Cab | 118 in |
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 69 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 480 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.1 mph |
| Shoe Size | 32 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 42,039 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 264 in |
|---|---|
| Max Reach Along Ground | 384 in |
| Max Loading Height | 317 in |
| Max Vertical Wall Digging Depth | 240 in |
| Max Cutting Height | 431 in |
| Shipping Length of Unit | 348 in |
| Shipping Height of Unit | 118 in |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.60 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 240 in |
|---|---|
| Max Vertical Wall Digging Depth | 216 in |
| Max Cutting Height | 414 in |
| Max Loading Height | 300 in |
| Max Reach Along Ground | 361 in |
| Shipping Length of Unit | 353 in |
| Shipping Height of Unit | 125 in |
