Case
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 49,318 lb |
|---|---|
| Fuel Capacity | 70.1 gal |
| Hydraulic Pump Flow Capacity | 106.2 gal/min |
| Hydraulic System Fluid Capacity | 54.5 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 6.4 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.2 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | BB-6BGIT |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 1,950 rpm |
| Net Power | 141.0 hp |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 137 in |
| Tail Swing Radius | 111 in |
| Width to Outside of Tracks | 101 in |
| Removal Counterweight Clearance | 43 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 22 in |
| Number of Shoes per Side | 47 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 220 in |
|---|---|
| Max Reach Along Ground | 347 in |
| Max Loading Height | 252 in |
| Max Vertical Wall Digging Depth | 191 in |
| Max Cutting Height | 362 in |
| Shipping Length of Unit | 378 in |
| Shipping Height of Unit | 120 in |
Bucket
| Reference Bucket Capacity | 1.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.70 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 239 in |
|---|---|
| Max Vertical Wall Digging Depth | 214 in |
| Max Cutting Height | 372 in |
| Max Loading Height | 261 in |
| Max Reach Along Ground | 364 in |
| Shipping Length of Unit | 378 in |
| Shipping Height of Unit | 122 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 263 in |
|---|---|
| Max Cutting Height | 383 in |
| Max Loading Height | 272 in |
| Max Vertical Wall Digging Depth | 238 in |
| Max Reach Along Ground | 385 in |
| Shipping Length of Unit | 374 in |
| Shipping Height of Unit | 117 in |
