Case
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
64 data points
Operating Specifications
| Operating Weight | 55,336 lb |
|---|---|
| Arm Breakout Force | 14,837 lb |
| Arm size | 118,111 in |
Engine
| Engine Model | Isuzu 4 HKIX |
|---|---|
| Displacement | 952 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 177.0 hp |
| Max Torque | 265 lb-ft |
| Engine Make | Isuzu |
| Stroke | 5 in |
| Bore | 5 in |
| Fuel Type | Requires ultra-low sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Interim Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Weights
| Counterweight | 8,157 lb |
|---|
Hydraulic System
| Main pump - Maximum flow | 123.7 gal |
|---|---|
| System relief pressure | 4,970 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Tail Swing Radius | 117 in |
| Overall Height | 126 in |
| Cab height | 120 in |
| Center to center - idler to sprocket | 144 in |
| Ground pressure | 6 psi |
| Boom length | 230 in |
| Minimum ground clearance | 17 in |
Transmission
| Max Speed | 3.5 mph |
|---|
Undercarriage
| Track Shoe Width | 24 in |
|---|
Brakes & Steering
| Service brake | SAHR disc - each motor |
|---|---|
| Brakes Type | Mechanical disc |
| Travel control | Dual stage relief or counter balance design |
Fluid Capacities
| Fuel Tank | 84.6 gal |
|---|---|
| Hydraulic system | 66.6 gal |
| Cooling system | 8.2 gal |
| Hydraulic Tank | 30.2 gal |
| Engine oil w/ filter change | 6.2 gal |
| Swing drive | 1.4 gal |
| Final Drive | 1.4 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 241 in |
|---|---|
| Max Reach Along Ground | 428 in |
| Max Vertical Wall Digging Depth | 216 in |
| Minimum swing radius | 100 in |
| Max.Dumping Height | 267 in |
| Max Digging Reach on Ground | 398 in |
| Bucket rotation | 177 ° |
| Mximum dig radius | 369 in |
| Dig radius at ground line | 362 in |
| Dump height | 300 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Vertical Wall Digging Depth | 234 in |
|---|---|
| Minimum swing radius | 91 in |
| Max Digging Reach | 263 in |
| Bucket rotation | 177 ° |
| Dig radius at ground line | 381 in |
| Dump height | 314 in |
| Maximum dig radius | 388 in |
| Maximum reach height | 427 in |
Boom/Stick Excavator Option 3
| Overall height | 126 in |
|---|
Performance
| Lift over end Max. reach | 5,864 lb |
|---|---|
| Lift over side Max. reach | 5,864 lb |
| Lift over end 10' radius | 20,172 lb |
| Lift over side 10' radius | 20,172 lb |
