Case
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 54,234 lb |
|---|---|
| Fuel Capacity | 108.4 gal |
| Hydraulic Pump Flow Capacity | 123.7 gal/min |
| Hydraulic System Fluid Capacity | 66.1 gal |
| Cooling System Fluid Capacity | 8.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | AL-4HK1X |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 177.1 hp |
| Torque Measured @ | 1,800 rpm |
| Max Torque | 458 lb-ft |
| Engine Make | Isuzu |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 126 in |
| Length of Track on Ground | 390 in |
| Tail Swing Radius | 117 in |
| Width to Outside of Tracks | 109 in |
Undercarriage
| Track Gauge | 102 in |
|---|---|
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 45,187 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 272 in |
|---|---|
| Max Reach Along Ground | 398 in |
| Max Loading Height | 267 in |
| Max Cutting Height | 385 in |
| Shipping Length of Unit | 126 in |
| Shipping Height of Unit | 390 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
