Case
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 8,466 lb |
|---|---|
| Fuel Capacity | 10.0 gal |
| Hydraulic Pump Flow Capacity | 20.2 gal/min |
| Hydraulic System Fluid Capacity | 12.7 gal |
| Hydraulic System Relief Valve Pressure | 3,336 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 24 A |
| Engine Oil Capacity | 1.8 gal |
| Cooling System Fluid Capacity | 1.2 gal |
Engine
| Engine Model | 3TNV88-BPYB |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 28.4 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,320 rpm |
| Max Torque | 59 lb-ft |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 102 in |
| Length of Track on Ground | 67 in |
| Tail Swing Radius | 33 in |
| Width to Outside of Tracks | 67 in |
| Removal Counterweight Clearance | 23 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 55 in |
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.8 mph |
| Shoe Size | 12 in |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 8,655 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 122 in |
|---|---|
| Max Reach Along Ground | 206 in |
| Max Vertical Wall Digging Depth | 95 in |
| Max Loading Height | 120 in |
| Shipping Length of Unit | 186 in |
| Max Cutting Height | 173 in |
| Shipping Height of Unit | 102 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.20 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 132 in |
|---|---|
| Max Cutting Height | 178 in |
| Max Loading Height | 125 in |
| Max Vertical Wall Digging Depth | 104 in |
| Max Reach Along Ground | 217 in |
| Shipping Height of Unit | 102 in |
| Shipping Length of Unit | 186 in |
