Case
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Operating Weight | 42,003 lb |
|---|---|
| Fuel Capacity | 85.9 gal |
| Hydraulic Pump Flow Capacity | 135.3 gal/min |
| Hydraulic System Fluid Capacity | 42.3 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 7.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Hydraulic Pump Type | 3 variable displacement axial piston |
| Tire Size | 18-22.5XF |
Engine
| Engine Model | 659TA-M2 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 173.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 109 in |
| Overall Width | 8 in |
| Tail Swing Radius | 109 in |
| Upper Structure Clearance | 53 in |
| Overall Width - Outriggers Down | 155 in |
Transmission
| Max Travel Speed | 18.7 mph |
|---|---|
| Transmission Type | powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 1.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.70 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 233 in |
|---|---|
| Max Cutting Height | 395 in |
| Max Reach Along Ground | 378 in |
| Max Loading Height | 288 in |
| Shipping Length of Unit | 381 in |
| Shipping Height of Unit | 126 in |
| Max Vertical Wall Dig Depth | 166 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 221 in |
|---|---|
| Max Cutting Height | 395 in |
| Max Reach Along Ground | 371 in |
| Max Loading Height | 284 in |
| Shipping Height of Unit | 127 in |
| Shipping Length of Unit | 381 in |
| Max Vertical Wall Dig Depth | 170 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 245 in |
|---|---|
| Max Cutting Height | 398 in |
| Max Reach Along Ground | 390 in |
| Max Loading Height | 292 in |
| Shipping Height of Unit | 130 in |
| Shipping Length of Unit | 381 in |
| Max Vertical Wall Dig Depth | 178 in |
