Caterpillar
JCB
JS240L
Excavator
13 specifications
Caterpillar
225
- Operating Weight
- 51,599 lb
- Max Digging Depth
- 288 in
- Max Digging Depth
- 312 in
- Net Power
- 135.0 hp
1 / 5
Image 1 of 5
Specifications
49 data points
Operating Specifications
| Operating Weight | 51,599 lb |
|---|---|
| Fuel Capacity | 65.0 gal |
| Hydraulic Pump Flow Capacity | 121.0 gal/min |
| Hydraulic System Fluid Capacity | 151.9 gal |
| Hydraulic System Relief Valve Pressure | 1,000 psi |
| Engine Oil Capacity | 3.3 gal |
| Cooling System Fluid Capacity | 10.1 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 7.6 gal |
| Alternator Supplied Amperage | 35 A |
Engine
| Engine Model | 3208 |
|---|---|
| Displacement | 635 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 135.0 hp |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 126 in |
| Length of Track on Ground | 155 in |
| Tail Swing Radius | 115 in |
| Width to Outside of Tracks | 124 in |
| Removal Counterweight Clearance | 49 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 97 in |
| Max Travel Speed | 1.8 mph |
| Shoe Size | 32 in |
| Drawbar Pull | 36,700 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 288 in |
|---|---|
| Max Reach Along Ground | 424 in |
| Max Loading Height | 229 in |
| Max Vertical Wall Digging Depth | 180 in |
| Max Cutting Height | 340 in |
| Shipping Length of Unit | 434 in |
| Shipping Height of Unit | 143 in |
Bucket
| Reference Bucket Capacity | 1.29 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.40 yd³ |
| Minimum Bucket Capacity | 0.80 yd³ |
Swing Mechanism
| Swing Speed | 2 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 312 in |
|---|---|
| Max Vertical Wall Digging Depth | 191 in |
| Max Cutting Height | 325 in |
| Max Loading Height | 228 in |
| Max Reach Along Ground | 378 in |
| Shipping Length of Unit | 433 in |
| Shipping Height of Unit | 148 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 277 in |
|---|---|
| Max Cutting Height | 343 in |
| Max Loading Height | 236 in |
| Max Vertical Wall Digging Depth | 162 in |
| Max Reach Along Ground | 401 in |
