Caterpillar

302.7D CR

Mini Excavator

Operating Weight
5,886 lb
Max Digging Depth
197 in
Gross Power
24.3 hp
Net Power
20.7 hp
All mini excavators
Caterpillar 302.7D CR Mini Excavator
1 / 5
Image 1 of 5
Image: veritread.com

Specifications

24 data points

Operating Specifications

Operating Specifications specifications
Operating Weight5,886 lb

Engine

Engine specifications
Engine ModelYanmar 3TNV76
Displacement68 in³
Gross Power24.3 hp
Net Power20.7 hp

Weights

Weights specifications
Operating Weight - With Cab5,886 lb
Operating Weight - With Canopy5,681 lb

Hydraulic System

Hydraulic System specifications
Operating Pressure - Equipment3,263 psi
Operating Pressure - Swing2,987 psi
Operating Pressure - Travel3,263 psi

Dimensions

Dimensions specifications
Tail Swing Radius30 in
Height95 in
Width62 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth197 in
Max Reach Along Ground180 in

General Specifications

General Specifications specifications
Net Power20.70 hp (15.44 kw) — Starting 2021 Model Year
Operating Weight6,239.00 lbs (2,829.97 kg) — Starting 2021 Model Year
Max Digging Depth61.90 ft (18.87 m) — Starting 2021 Model Year
Engine31NV76 — Starting 2021 Model Year

Service Refill Capacities

Service Refill Capacities specifications
Fuel Tank Capacity9.3 gal

Blades

Blades specifications
Blade Width62 in
Blade Height11 in
Blade Lift Height15 in
Dig Depth17 in
