Caterpillar
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 7,782 lb |
|---|
Engine
| Engine Model | Cat C1.3 |
|---|---|
| Displacement | 77 in³ |
| Gross Power | 24.8 hp |
| Net Power | 23.5 hp |
| Bore | 3 in |
| Stroke | 4 in |
Weights
| Operating Weight - With Cab | 7,204 lb |
|---|---|
| Operating Weight - With Canopy | 6,721 lb |
Hydraulic System
| Operating Pressure - Equipment | 3,553 psi |
|---|---|
| Operating Pressure - Swing | 2,625 psi |
| Operating Pressure - Travel | 3,553 psi |
| Digging Force - Bucket | 6,385 lb |
| Digging Force - Stick - Standard | 3,732 lb |
| Digging Force - Stick - Long | 3,327 lb |
| Hydraulic System Type | Load Sensing Hydraulics with Variable Displacement Piston Pump |
| Pump Flow at 2,400 rpm | 23.1 gal/min |
Boom/Stick Excavator Option 1
| Max Digging Depth | 108 in |
|---|---|
| Max Reach Along Ground | 190 in |
Service Refill Capacities
| Engine Oil | 1.5 gal |
|---|---|
| Hydraulic Tank | 12.4 gal |
| Fuel Tank | 11.9 gal |
| Hydraulic System | 17.2 gal |
| Cooling System | 1.2 gal |
Blades
| Blade Width | 60 in |
|---|---|
| Blade Height | 13 in |
| Blade Lift Height | 16 in |
| Dig Depth | 19 in |
Swing System
| Machine Swing Speed | 9 rpm |
|---|---|
| Boom Swing - Left - Without Stop | 80 ° |
Travel System
| Travel Speed - High | 2.8 mph |
|---|---|
| Travel Speed - Low | 1.5 mph |
| Maximum Traction Force - High Speed | 3,417 lb |
| Maximum Traction Force - Low Speed | 6,947 lb |
