E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 33,069 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic System Fluid Capacity | 43.4 gal |
| Engine Oil Capacity | 3.6 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Swing Drive Fluid Capacity | 0.7 gal |
Engine
| Engine Model | C4.4 ACERT |
|---|---|
| Displacement | 269 in³ |
| Net Power | 94.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 109 in |
| Length of Track on Ground | 138 in |
| Tail Swing Radius | 85 in |
| Removal Counterweight Clearance | 36 in |
Undercarriage
| Number of Track Rollers per Side | 7 |
|---|---|
| Number of Shoes per Side | 46 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 25,628 lb |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
