Caterpillar
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 33,080 lb |
|---|
Engine
| Engine Model | C4.4 ACERT |
|---|---|
| Displacement | 269 in³ |
| Stroke | 5 in |
| Bore | 4 in |
| Flywheel Power | 92.0 hp |
Hydraulic System
| Maximum Pressure - Swing | 3,336 psi |
|---|---|
| Maximum Pressure - Travel | 5,076 psi |
| Maximum Pressure - Equipment | 4,424 psi |
| Pilot System - Maximum Pressure | 598 psi |
| Main System - Maximum Flow (total) | 67.0 gal/min |
General Specifications
| Net Power | 92.00 hp (68.61 kw) Starting 2021 Model Year |
|---|---|
| Operating Weight | 33,000.00 lbs (14,968.57 kg) Starting 2021 Model Year |
| Max Digging Depth | 19.80 ft (6.04 m) Starting 2021 Model Year |
| Engine | C4.4 Starting 2021 Model Year |
Drive System
| Maximum Drawbar Pull | 25,628 lb |
|---|---|
| Maximum Travel Speed | 3.7 mph |
Service Refill Capacities
| Cooling System | 5.9 gal |
|---|---|
| Final Drive - Each | 0.8 gal |
| Fuel Tank Capacity | 58.9 gal |
| Swing Drive | 0.7 gal |
Swing
| Swing Speed | 11 rpm |
|---|---|
| Swing Torque | 22,791 lb-ft |
Comparable machines
Other excavators in a similar weight class.
