Caterpillar
322L
- Operating Weight
- 54,851 lb
- Max Digging Depth
- 231 in
- Max Digging Depth
- 247 in
- Net Power
- 152.9 hp
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 54,851 lb |
|---|---|
| Fuel Capacity | 97.8 gal |
| Hydraulic Pump Flow Capacity | 108.4 gal/min |
| Hydraulic System Fluid Capacity | 71.4 gal |
Engine
| Engine Model | 3116T |
|---|---|
| Displacement | 6,600 in³ |
| Power Measured @ | 1,950 rpm |
| Net Power | 152.9 hp |
| Engine Make | Caterpillar |
Dimensions
| Length of Track on Ground | 151 in |
|---|---|
| Width to Outside of Tracks | 126 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 231 in |
|---|---|
| Max Reach Along Ground | 359 in |
| Max Loading Height | 246 in |
| Max Cutting Height | 370 in |
| Shipping Length of Unit | 398 in |
| Shipping Height of Unit | 124 in |
Boom/Stick Excavator Option 2
| Max Digging Depth | 247 in |
|---|---|
| Max Cutting Height | 374 in |
| Max Loading Height | 258 in |
| Max Reach Along Ground | 378 in |
| Shipping Length of Unit | 395 in |
| Shipping Height of Unit | 124 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 265 in |
|---|---|
| Max Cutting Height | 381 in |
| Max Loading Height | 265 in |
| Max Reach Along Ground | 395 in |
| Shipping Length of Unit | 393 in |
| Shipping Height of Unit | 124 in |
