Volvo
ECR145CL
- Operating Weight
- 32,980 lb
- Max Digging Depth
- 203 in
- Max Digging Depth
- 219 in
- Net Power
- 92.0 hp
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Operating Weight | 32,980 lb |
|---|---|
| Fuel Capacity | 58.2 gal |
| Hydraulic Pump Flow Capacity | 62.0 gal/min |
| Hydraulic System Fluid Capacity | 55.5 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 4.1 gal |
| Cooling System Fluid Capacity | 5.7 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.1 gal |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | D4E EAE3 |
|---|---|
| Displacement | 246 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 107.0 hp |
| Net Power | 92.0 hp |
| Aspiration | Turbocharged with Intercooler |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 354 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 113 in |
| Length of Track on Ground | 120 in |
| Tail Swing Radius | 59 in |
| Width to Outside of Tracks | 102 in |
| Removal Counterweight Clearance | 36 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 46 |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 27,120 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 203 in |
|---|---|
| Max Reach Along Ground | 309 in |
| Max Loading Height | 258 in |
| Max Vertical Wall Digging Depth | 152 in |
| Max Cutting Height | 357 in |
| Shipping Length of Unit | 292 in |
| Shipping Height of Unit | 107 in |
Bucket
| Reference Bucket Capacity | 0.90 yd³ |
|---|
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 219 in |
|---|---|
| Max Vertical Wall Digging Depth | 167 in |
| Max Cutting Height | 371 in |
| Max Loading Height | 271 in |
| Max Reach Along Ground | 324 in |
| Shipping Length of Unit | 292 in |
| Shipping Height of Unit | 113 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 239 in |
|---|---|
| Max Cutting Height | 388 in |
| Max Loading Height | 288 in |
| Max Vertical Wall Digging Depth | 189 in |
| Max Reach Along Ground | 343 in |
| Shipping Length of Unit | 289 in |
| Shipping Height of Unit | 130 in |
