Caterpillar
Kobelco
SK500LC-10
Excavator
53 specifications
1 / 5
Image 1 of 5
Specifications
57 data points
Operating Specifications
| Operating Weight | 190,204 lb |
|---|---|
| Fuel Capacity | 328,291.8 gal |
| Hydraulic Pump Flow Capacity | 266.0 gal/min |
| Hydraulic System Fluid Capacity | 263.0 gal |
| Engine Oil Capacity | 16.0 gal |
| Cooling System Fluid Capacity | 20.0 gal |
| Swing Drive Fluid Capacity | 5.0 gal |
Engine
| Engine Model | Cat C18 ACERT |
|---|---|
| Displacement | 1,105 in³ |
| Net Power | 524.0 hp |
| Engine Make | Caterpillar |
| Stroke | 7 in |
| Bore | 6 in |
| Net Power - SAE J1349 | 524.0 hp |
Weights
| Operating Weight | 190,204 lb |
|---|---|
| Maximum Operating Weight | 190,204 lb |
| Minimum Operating Weight | 156,461 lb |
Hydraulic System
| Maximum Pressure - Swing | 3,770 psi |
|---|---|
| Maximum Pressure - Travel | 5,076 psi |
| Boom Cylinder - Bore | 8 in |
| Boom Cylinder - Stroke | 77 in |
| Stick Cylinder - Bore | 9 in |
| Stick Cylinder - Stroke | 89 in |
| Maximum Pressure - Equipment - Normal | 5,076 psi |
| Swing System - Maximum Flow | — |
| Pilot System - Maximum Pressure | 580 – 638 psi |
| Main System - Maximum Flow ( 2 pumps) - Implement | 133.0 gal/min |
| Main System - Maximum Flow ( 2 pumps) - Travel | 141.0 gal/min |
| Main System - Maximum Flow - Total - Implement | 266.0 gal/min |
| Main System - Maximum Flow - Total - Travel | 281.0 gal/min |
Dimensions
| Ground Clearance | 36 in |
|---|---|
| Height - Top of Cab | 151 in |
| Length of Track on Ground | 251 in |
| Tail Swing Radius | 186 in |
| Width to Outside of Tracks | 109 in |
| Removal Counterweight Clearance | 65 in |
Undercarriage
| Number of Track Rollers per Side | 9 |
|---|---|
| Max Travel Speed | 2.8 mph |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 3 |
| Drawbar Pull | 132,637 lb |
Drive System
| Maximum Drawbar Pull | 132,637 lb |
|---|
Service Refill Capacities
| Cooling System | 20.0 gal |
|---|---|
| Hydraulic System - Including Tank | 263.0 gal |
| Final Drive - Each | 5.5 gal |
| Engine Oil | 16.0 gal |
| Hydraulic Tank | 215.0 gal |
| Fuel Tank Capacity | 328.0 gal |
| Swing Drive - Each | 5.0 gal |
| DEF Tank | 13.0 gal |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
Standards
| Brakes | SAE J1026 APR90 |
|---|---|
| Cab/FOGS | SAE J1356 FEB88 ISO 10262 |
Track
| Number of Shoes - Each Side - Long Undercarriage | 51 |
|---|---|
| Number of Track Rollers - Each Side - Long Undercarriage | 9 |
| Standard with Long Undercarriage | 35 in |
| Optional for Long Undercarriage (1) | 26 in |
