Hitachi
ZX520LCR-3
- Operating Weight
- 115,743 lb
- Max Digging Depth
- 226 in
- Max Digging Depth
- 239 in
- Net Power
- 349.0 hp
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 115,743 lb |
|---|---|
| Fuel Capacity | 191.6 gal |
| Hydraulic Pump Flow Capacity | 190.3 gal/min |
| Hydraulic System Fluid Capacity | 148.0 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 15.1 gal |
| Cooling System Fluid Capacity | 14.6 gal |
| Swing Drive Fluid Capacity | 1.8 gal |
Engine
| Engine Model | AH-6WG1XYSA-01 |
|---|---|
| Displacement | 957 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 349.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 1,165 lb-ft |
Dimensions
| Ground Clearance | 32 in |
|---|---|
| Height - Top of Cab | 139 in |
| Length of Track on Ground | 168 in |
| Tail Swing Radius | 144 in |
| Width to Outside of Tracks | 139 in |
| Removal Counterweight Clearance | 57 in |
Undercarriage
| Ground Pressure | 14 psi |
|---|---|
| Track Gauge | 115 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 2.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 226 in |
|---|---|
| Max Reach Along Ground | 402 in |
| Max Loading Height | 292 in |
| Max Vertical Wall Digging Depth | 166 in |
| Max Cutting Height | 424 in |
Bucket
| Reference Bucket Capacity | 2.50 yd³ |
|---|
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 239 in |
|---|---|
| Max Vertical Wall Digging Depth | 180 in |
| Max Cutting Height | 428 in |
| Max Loading Height | 296 in |
| Max Reach Along Ground | 414 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 281 in |
|---|---|
| Max Cutting Height | 403 in |
| Max Loading Height | 283 in |
| Max Vertical Wall Digging Depth | 166 in |
| Max Reach Along Ground | 437 in |
| Shipping Height of Unit | 138 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 304 in |
|---|---|
| Max Cutting Height | 439 in |
| Max Reach Along Ground | 466 in |
| Max Loading Height | 305 in |
| Max Vertical Wall Dig Depth | 277 in |
| Shipping Length of Unit | 469 in |
