Caterpillar
Case
480E
Backhoe Loader
42 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight 4wd | 17,505 lb |
|---|---|
| Fuel Capacity | 38.4 gal |
| Hydraulic System Fluid Capacity | 10.1 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Turning Radius | 181 in |
| Transmission Fluid Capacity | 5.1 gal |
| Rear Axle Fluid Capacity | 4.3 gal |
| Front Axle Fluid Capacity | 3.0 gal |
Engine
| Engine Model | 3054C |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 102.0 hp |
| Net Power | 99.0 hp |
| Number of Cylinders | 4 |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 41.3 gal/min |
|---|---|
| Relief Valve Pressure | 249 psi |
| Pump Type | Variable-Flow Axial-Piston |
Dimensions
| Wheelbase | 88 in |
|---|---|
| Transport Width | 94 in |
| Transport Length | 229 in |
| Height to Top of Suspended Cab | 113 in |
Transmission
| Max Speed | 26.1 mph |
|---|---|
| Max Speed - Reverse | 25.5 mph |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 5 |
| Transmission Type | Power-Shuttle |
Backhoe
| Dig Depth | 211 in |
|---|---|
| Reach From Swivel | 238 in |
| Dig Depth - Extended | 258 in |
| Load Height - Extended | 182 in |
| Load Height | 161 in |
Loader
| Bucket Capacity | 1.40 yd³ |
|---|---|
| Clearance at Max Dump Height | 106 in |
| Bucket Breakout Force | 11,465 lb |
| Bucket Width | 95 in |
| Dig Depth | 4 in |
