Caterpillar
John Deere
2154D Butt TOP
Log Loader
Specifications pending
1 / 5
Image 1 of 5
Specifications
15 data points
Operating Specifications
| Electric Motor | 75.0 hp |
|---|---|
| Electric Power Supply | 460 Volt: 60 HZ |
| Grapple Mounting Knuckle Length | 9 in |
| Knuckleboom Length | 324 in |
| Swing Bearing - Diameter | 43 in |
| Swing Bearing - Gearing | External |
Engine
| Gross Power | 75.0 hp |
|---|
Hydraulic System
| Hydraulic Flow | 167/125/83 L/min (44/33/22 gpm) |
|---|---|
| Cylinders - Live Heel | 127 mm X 76 mm (5 in X 3 in) |
| Cylinders - Main | 152 mm X 102 mm (6 in X 4 in) |
| Cylinders - Stick | 152 mm X 102 mm (6 in X 4 in) |
| Hydraulic Pressure - Swing | 2,400 psi |
| Hydraulic Pressure - System | 2,200 psi |
| Swing Speed | 8 rpm |
Service Refill Capacities
| Fuel Tank | 42.0 gal |
|---|
