Specifications
58 data points
Operating Specifications
| Operating Weight w/o Attachment | 59,710 lb |
|---|---|
| Operating Weight | 57,431 lb |
| Fuel Capacity | 140.1 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 95 A |
| Hydraulic System Fluid Capacity | 79.3 gal |
| Cooling System Fluid Capacity | 16.2 gal |
| Engine Oil Capacity | 10.4 gal |
| Bare Pin Lift at Maximum Reach - Without Attachment | 7100 kg (15600 lb) @ 6.1 m (20 ft) |
| Bare Pin Lift at Maximum Reach - Without Attachment - Track Harvester Configuration | 4100 kg (9100 lb) @ 9 m (29.5 ft) |
| Maximum Reach - With Attachment | 319 in |
| Maximum Reach - With Attachment - Track Harvester Configuration | 384 in |
Engine
| Engine Model | Cat C9 ACERT |
|---|---|
| Displacement | 537 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 284.0 hp |
| Net Power | 263.0 hp |
| Rated Power | 263.0 hp |
Weights
| Operating Weight - Without Attachment | 59,710 lb |
|---|---|
| Operating Weight - Without Attachment - Track Harvester Configuration | 57,440 lb |
Hydraulic System
| Pump Size - Boom, Implements | 12 in³ |
|---|---|
| Pump Size - Saw Motor | 3 in³ |
| Pump Size - Travel Circuit | 12 in³ |
Dimensions
| Ground Clearance | 3 in |
|---|---|
| Height - Top of Cab | 141 in |
| Overall Length | 341 in |
| Overall Width | 126 in |
| Height | 141 in |
| Shipping Length - non tilt | 454 in |
| Max Reach | 319 in |
| Shipping Length - With Attachment | 431 in |
| Shipping Length - Without Attachment | 340 in |
| Width - Minimum | 126 in |
Undercarriage
| Track Gauge | 190 in |
|---|---|
| Shoe Size | 24 in |
| Track Pitch | 8 in |
| Ground Clearance | 33 in |
| Tractive Effort | 70,499 lb |
| Track Length | 190 in |
Boom
| Lift Capacity at Max Reach | 9,039 lb |
|---|---|
| Bare Pin Lift at Max Reach | 15,653 lb |
| Max Reach w/ Head | 386 in |
Service Refill Capacities
| Fuel Tank | 140.0 gal |
|---|---|
| Cooling System | 16.1 gal |
| Engine Oil | 10.3 gal |
| Hydraulic Tank | 69.2 gal |
| Swing Drive | 2.6 gal |
| Hydraulic System | 79.3 gal |
| Pony Fuel Tank - Optional | 90.0 gal |
Track
| Ground Clearance | 33 in |
|---|---|
| Track Length | 189 in |
| Tractive Effort | 70,500 lb |
| Undercarriage Pitch | 8 in |
| Undercarriage Size | D6H HD |
| Track Gauge | 102 in |
Dimensions - Track Harvester Configuration
| Height - Without Attachment | 140 in |
|---|---|
| Shipping Length - Without Attachment | 453 in |
| Width - Minimum - Without Attachment | 126 in |
