822C
Feller Buncher
19 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight w/o Attachment | 78,661 lb |
|---|---|
| Operating Weight | 79,366 lb |
| Fuel Capacity | 312.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 95 A |
| Hydraulic System Fluid Capacity | 97.8 gal |
| Cooling System Fluid Capacity | 16.2 gal |
| Engine Oil Capacity | 10.4 gal |
Engine
| Engine Model | C9 ACERT |
|---|---|
| Displacement | 537 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 305.0 hp |
| Net Power | 282.0 hp |
Dimensions
| Ground Clearance | 3 in |
|---|---|
| Height - Top of Cab | 156 in |
| Overall Length | 372 in |
| Overall Width | 132 in |
| Forward Tilt | 20 ° |
| Side Tilt | 11 ° |
| Max Reach | 340 in |
| Shipping Length - tilt | 276 in |
Undercarriage
| Track Gauge | 103 in |
|---|---|
| Shoe Size | 28 in |
| Track Pitch | 9 in |
| Ground Clearance | 36 in |
| Tractive Effort | 104,001 lb |
| Track Length | 192 in |
Boom
| Lift Capacity at Max Reach | 12,566 lb |
|---|---|
| Bare Pin Lift at Max Reach | 20,723 lb |
| Max Reach w/ Head | 445 in |
Upperstructure Leveling
| Front | 20 ° |
|---|---|
| Side | 11 ° |
