Caterpillar
Valmet
860.3
Forwarder
28 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight - 8wd | 28,500 lb |
|---|---|
| Fuel Capacity | 23.8 gal |
| Front/Rear Tire Size - 8wd | 600/50-22.5 12PR B |
| Maximum Travel Speed | 15.5 mph |
| Payload | 22,046 lb |
| Loader Net Lifting Capacity | 466 lb |
| Tractive Ability | 28,102 lb |
| Travel Speed - Roading | 15.5 mph |
Engine
| Engine Model | 3054 DITA |
|---|---|
| Displacement | 243 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 122.0 hp |
| Torque Measured @ | 1,600 rpm |
| Power | 111.4 hp |
| Torque | 329 lb-ft |
| Flywheel Power | 111.0 hp |
Weights
| Gross (Loaded) Machine Weight | 48,446 lb |
|---|
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Width Over Tires | 102 in |
| Length | 341 in |
| Length of Bunk Area | 190 in |
| Width of Bunk Area | 102 in |
Transmission
| Max Speed | 15.5 mph |
|---|---|
| Transmission Type | Hydrostatic/Mechanical |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
| Transmission | Powershift |
Performance
| Reach - Maximum - Any Height | 333 in |
|---|
Fuel Tank
| Fuel Tank Capacity | 23.4 gal |
|---|
Bunk
| Load Weight - 8wd | 22,000 lb |
|---|
Crane
| Max Reach | 282 in |
|---|---|
| Gross Lift Torque | 15,300 lb-ft |
| Crane Type | F61 F72 |
