Komatsu
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight - 6wd | 23,149 lb |
|---|---|
| Fuel Capacity | 26.5 gal |
| Hydraulic System Fluid Capacity | 21.2 gal |
| Alternator Supplied Amperage | 110 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 8wd | 600/50x22.5 |
| Front/Rear Tire Size - 6wd | 600/50x22.5 |
Engine
| Engine Model | 44 CWA Tier 3 |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 4 |
| Aspiration | Turbo |
| Torque Measured @ | 1,500 rpm |
| Power | 134.0 hp |
| Torque | 440 lb-ft |
Hydraulic System
| Pump Type | single circuit load sensing with variable piston pump |
|---|---|
| Relief Valve Pressure | 3,410 psi |
| Flow Capacity | 45.0 gal/min |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 165 in |
| Width Over Tires | 104 in |
| Length | 320 in |
| Length of Bunk Area | 91 in |
Transmission
| Max Speed | 15.6 mph |
|---|---|
| Transmission Type | hydrostatic |
Bunk
| Load Area | 17.62 yd³ |
|---|---|
| Load Weight - 6wd | 43,762 lb |
Crane
| Max Reach | 270 in |
|---|---|
| Gross Lift Torque | 54,599 lb-ft |
| Crane Type | CRF 5 |
| Gross Slew Torque | 16,150 lb-ft |
