554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight - 6wd | 27,558 lb |
|---|---|
| Operating Weight 4wd | 27,558 lb |
| Fuel Capacity | 29.9 gal |
| Hydraulic System Fluid Capacity | 50.2 gal |
| Alternator Supplied Amperage | 100 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 6wd | 600-34/14 / 600-26.5/20 |
| Front/Rear Tire Size - 4wd | 600x34/14 |
Engine
| Engine Model | 4045H |
|---|---|
| Power Measured @ | 2,000 rpm |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Power | 115.0 hp |
| Torque | 367 lb-ft |
Hydraulic System
| Flow Capacity | 39.7 gal/min |
|---|
Dimensions
| Ground Clearance | 24 in |
|---|
Transmission
| Max Speed | 13.7 mph |
|---|---|
| Transmission Type | hydrostatic/mechanical |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bunk
| Load Weight - 6wd | 22,046 lb |
|---|
Crane
| Gross Lift Torque | 75,230 lb-ft |
|---|---|
| Crane Type | Timberjack CF 5 72 |
