Valmet
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight - 8wd | 23,150 lb |
|---|---|
| Hydraulic System Fluid Capacity | 21.0 gal |
| Alternator Supplied Amperage | 100 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 8wd | 700 / 45X22.5 - 710 / 40X22.5 |
| Front/Rear Tire Size - 6wd | 600 / 50X22.5 - 650 /45X22.5 |
Engine
| Engine Model | 44 CWA Turbo W/ Commonrail.Tier 3 |
|---|---|
| Power | 134.0 hp |
| Torque | 440 lb-ft |
Hydraulic System
| Pump Type | Variable Piston Pump |
|---|---|
| Relief Valve Pressure | 3,410 psi |
| Flow Capacity | 45.0 gal/min |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 73 in |
| Width Over Tires | 103 in |
| Length | 320 in |
| Length of Bunk Area | 91 in |
Transmission
| Max Speed | 15.0 mph |
|---|---|
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 8 |
| Number of Reverse Gears | 8 |
Bunk
| Load Area | 2.96 yd³ |
|---|---|
| Load Weight - 8wd | 19,850 lb |
Crane
| Max Reach | 270 in |
|---|---|
| Gross Lift Torque | 54,599 lb-ft |
| Crane Type | CRF 5 |
| Gross Slew Torque | 16,150 lb-ft |
