Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
95 data points
Operating Specifications
| Fuel Capacity | 95.2 gal |
|---|---|
| Tire Size | 23.5R25 |
| Engine Oil Capacity | 9.8 gal |
| Cooling System Fluid Capacity | 22.5 gal |
| Hydraulic System Fluid Capacity | 27.0 gal |
| Transmission Fluid Capacity | 9.6 gal |
Engine
| Engine Model | Cat C11 ACERT |
|---|---|
| Displacement | 680 in³ |
| Gross Power | 313.0 hp |
| Net Power | 309.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Make | Cat |
| Bore | 5 in |
| Stroke | 6 in |
| Gross Power - SAE J1995 | 309.0 hp |
| Net Power - ISO 9249 | 304.0 hp |
| Net Power - SAE J1349 | 301.0 hp |
| Net Power - EEC 80/1269 | 304.0 hp |
| Flywheel Power | 301.0 hp |
Weights
| Operating Weight | 97,880 lb |
|---|---|
| Total Empty | 49,075 lb |
| Front Axle - empty | 28,704 lb |
| Total Loaded | 101,082 lb |
| Rear Axle - empty | 49,075 lb |
| Front Axle - loaded | 33,136 lb |
| Rear Axle - loaded | 33,510 lb |
| Center Axle - empty | 10,648 lb |
| Center Axle - loaded | 34,436 lb |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 185 in |
| Overall Length | 391 in |
| Overall Width | 114 in |
| Overall Height | 135 in |
| Dump Height | 253 in |
| Dump Ground Clearance | 23 in |
Transmission
| Max Speed | 35.3 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
| Forward - 1 | 4.9 mph |
| Forward - 2 | 9.3 mph |
| Forward - 3 | 14.0 mph |
| Forward - 4 | 21.5 mph |
| Forward - 5 | 29.9 mph |
| Forward - 6 | 35.3 mph |
| Reverse - 1 | 5.5 mph |
General Specifications
| Operating Weight lbs (kg) | 50,795 (23,040) Starting 2024 Model Year |
|---|---|
| Engine type | Cat C9.3 Starting 2024 Model Year |
| Articulated/Rigid | Articulated Starting 2024 Model Year |
| Drive Configuration | 6WD Starting 2024 Model Year |
| Rated Payload Tons (Metric Tons) | 26.5 (24) Starting 2024 Model Year |
| Mfg. Model | 725 Starting 2024 Model Year |
| Planetary Powershift Transmission | Powershift w/ lockup torque converter Starting 2024 Model Year |
Service Refill Capacities
| Cooling System | 22.7 gal |
|---|---|
| Fuel Tank | 95.0 gal |
| Engine Crankcase | 9.8 gal |
| Hydraulic System | 26.4 gal |
| Transmission | 9.5 gal |
| Output Transfer Gear Box | 4.8 gal |
| Final Drives/Differential | 34.9 gal |
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 52,029 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 10.0 s |
| Lower Time | 11.0 s |
| Capacity - Heaped | 18.80 yd³ |
| Capacity - Struck | 14.60 yd³ |
Standards
| Brakes | ISO 3450 - 1996 |
|---|---|
| Cab - ROPS | ISO 3471-1994 |
| Steering | ISO 5010 - 2007 |
| Cab - FOPS | ISO 3449 level ll - 2005 |
Operating Weights
| Total - Empty | 49,075 lb |
|---|---|
| Total - Rated Load | 52,007 lb |
| Center Axle - Empty | 10,648 lb |
| Center Axle - Loaded | 34,336 lb |
| Center Axle - Rated Load | 23,788 lb |
| Front Axle - Empty | 28,704 lb |
| Front Axle - Loaded | 33,135 lb |
| Front Axle - Rated Load | 4,431 lb |
| Rear Axle - Empty | 9,722 lb |
| Rear Axle - Loaded | 33,510 lb |
| Rear Axle - Rated Load | 23,788 lb |
| Total - Loaded | 101,082 lb |
Body
| Plate thickness-Front | 0 in |
|---|
Body Plate
| Type | High strength Brinell HB450 wear resistant steel |
|---|
Body Plate Thickness
| Base | 1 in |
|---|---|
| Side | 1 in |
| Scow | 1 in |
Body Capacities
| Heaped (SAE 2:1) | 18.80 yd³ |
|---|---|
| Struck | 14.51 yd³ |
| Tailgate Heaped SAE 2:1 | 20.00 yd³ |
| Tailgate Struck | 15.00 yd³ |
Body Hoist
| Lower Time | 8.0 s |
|---|---|
| Raise Time | 10.0 s |
Sound Levels
| Interior Cab | 76 dB(A) |
|---|
