Caterpillar
Terex
TA27
Off-Highway Truck
46 specifications
1 / 5
Image 1 of 5
Specifications
105 data points
Operating Specifications
| Fuel Capacity | 95.2 gal |
|---|---|
| Tire Size | 23.5R25 |
| Engine Oil Capacity | 9.8 gal |
| Cooling System Fluid Capacity | 22.5 gal |
| Hydraulic System Fluid Capacity | 27.0 gal |
| Transmission Fluid Capacity | 9.6 gal |
Engine
| Engine Model | Cat C13 ACERT |
|---|---|
| Displacement | 763 in³ |
| Gross Power | 329.0 hp |
| Net Power | 325.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbochaarged |
| Make | Cat |
| Stroke | 6 in |
| Bore | 5 in |
| Gross Power - SAE J1995 | 375.0 hp |
| Net Power - ISO 9249 | 321.0 hp |
| Net Power - SAE J1349 | 367.0 hp |
| Net Power - EEC 80/1269 | 321.0 hp |
| Net Power - ISO 14396 | 370.0 hp |
| Peak Engine Torque Gross (SAE J1995) | 1,579 lb-ft |
| Peak Engine Torque Speed | 1,200 rpm |
| Peak Engine Torque Net (SAE J1349) | 1,564 lb-ft |
| Engine Model - U.S. EPA Tier 4 Final/EU Stage IV | Cat C13 ACERT |
Weights
| Operating Weight | 109,600 lb |
|---|---|
| Total Empty | 50,376 lb |
| Front Axle - empty | 28,969 lb |
| Total Loaded | 112,370 lb |
| Rear Axle - empty | 10,384 lb |
| Front Axle - loaded | 34,965 lb |
| Rear Axle - loaded | 38,383 lb |
| Center Axle - empty | 11,023 lb |
| Center Axle - loaded | 39,022 lb |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 185 in |
| Overall Length | 391 in |
| Overall Width | 114 in |
| Overall Height | 135 in |
| Dump Height | 257 in |
| Dump Ground Clearance | 23 in |
Transmission
| Max Speed | 34.4 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
| Forward - 1 | 5.0 mph |
| Forward - 2 | 9.0 mph |
| Forward - 3 | 14.0 mph |
| Forward - 4 | 21.0 mph |
| Forward - 5 | 29.0 mph |
| Forward - 6 | 34.0 mph |
| Reverse - 1 | 6.0 mph |
General Specifications
| Operating Weight lbs (kg) | 52,690 (23,900) Starting 2019 Model Year |
|---|---|
| Engine type | Cat C13 Starting 2024 Model Year |
| Articulated/Rigid | Articulated Starting 2024 Model Year |
| Drive Configuration | 6WD Starting 2019 Model Year |
| Rated Payload Tons (Metric Tons) | 31 (28) Starting 2019 Model Year |
| Mfg. Model | 730 Starting 2019 Model Year |
| Planetary Powershift Transmission | Powershift w/ lockup torque converter Starting 2019 Model Year |
Drive System
| Drive Config | 6x6 |
|---|
Service Refill Capacities
| Cooling System | 21.9 gal |
|---|---|
| Fuel Tank | 108.8 gal |
| Engine Crankcase | 10.0 gal |
| Hydraulic System | 29.1 gal |
| Transmission | 12.4 gal |
| Output Transfer Gear Box | 6.3 gal |
| Final Drives/Differential | 33.0 gal |
| DEF Tank | 5.3 gal |
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 61,950 lb |
|---|---|
| Raise Time | 12.0 s |
| Lower Time | 12.0 s |
| Capacity - Heaped | 22.20 yd³ |
| Capacity - Struck | 17.20 yd³ |
Standards
| Brakes | ISO 3450 2011 |
|---|---|
| Cab - ROPS | ISO 3471 2008 |
| Steering | ISO 5010 2007 |
| Cab - FOPS | ISO 3449 Level II 2005 |
Steering System
| Lock to Lock | 4.75 seconds @ 60 rpm |
|---|
Operating Weights
| Total - Empty | 52,690 lb |
|---|---|
| Total - Rated Load | 61,729 lb |
| Center Axle - Empty | 10,053 lb |
| Center Axle - Loaded | 37,302 lb |
| Center Axle - Rated Load | 27,249 lb |
| Front Axle - Empty | 33,069 lb |
| Front Axle - Loaded | 40,300 lb |
| Front Axle - Rated Load | 7,231 lb |
| Rear Axle - Empty | 9,568 lb |
| Rear Axle - Loaded | 36,817 lb |
| Rear Axle - Rated Load | 27,249 lb |
| Total - Loaded | 114,420 lb |
Body
| Plate thickness-Front | 0 in |
|---|
Body Plate
| Body Plate Type | High strength Brinell HB450 wear resistant steel |
|---|
Body Plate Thickness
| Base | 1 in |
|---|---|
| Side | 1 in |
| Scow | 1 in |
Turning Circle
| Turning Dimensions - Aisle Width | 210 in |
|---|---|
| Turning Dimensions - Clearance Radius | 318 in |
| Turning Dimensions - Inside Radius | 153 in |
| Turning Dimensions - SAE Turning Radius | 294 in |
Body Capacities
| Heaped (SAE 2:1) | 22.99 yd³ |
|---|---|
| Struck | 17.40 yd³ |
| Tailgate Heaped SAE 2:1 | 24.60 yd³ |
| Tailgate Struck | 18.19 yd³ |
Body Hoist
| Lower Time | 8.0 s |
|---|---|
| Raise Time | 12.0 s |
Sound Levels
| Interior Cab | 72 dB(A) |
|---|
