Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Fuel Capacity | 140.1 gal |
|---|---|
| Tire Size | 18-33 28 PR |
| Engine Oil Capacity | 11.9 gal |
| Cooling System Fluid Capacity | 30.0 gal |
| Hydraulic System Fluid Capacity | 96.2 gal |
| Operating Voltage | 24 V |
| Steering System Fluid Capacity | 14.6 gal |
| Diff and Final Drive Fluid Capacity | 22.0 gal |
| Brake/Hoist System Fluid Capacity | 58.2 gal |
Engine
| Engine Model | 3408 |
|---|---|
| Displacement | 1,099 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 474.0 hp |
| Net Power | 450.0 hp |
| Number of Cylinders | 8 |
| Torque Measured @ | — |
| Rated Engine Speed | 96 rpm |
Weights
| Empty Weight | 67,627 lb |
|---|---|
| Loaded Weight | 149,002 lb |
| Weight Distribution Front - loaded | 33.3 % |
| Weight Distribution Rear - loaded | 67.7 % |
| Weight Distribution Front - empty | 49.6 % |
| Weight Distribution Rear - empty | 50.4 % |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 146 in |
| Overall Length | 316 in |
| Overall Width | 179 in |
| Overall Height | 149 in |
| Dump Height | 304 in |
| Dump Ground Clearance | 23 in |
Transmission
| Max Speed | 46.8 mph |
|---|---|
| Transmission Type | electronically controlled power shift |
| Number of Gears - Forward | 7 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 80,991.2 gal |
|---|
Dump
| Rated Payload | 81,000 lb |
|---|---|
| Raise Time | 11.0 s |
| Lower Time | 11.4 s |
| Load Capacity - heaped | 30.89 yd³ |
| Load Capacity - Struck | 22.90 yd³ |
