Caterpillar
Terex
TA27
Off-Highway Truck
46 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Fuel Capacity | 140.1 gal |
|---|---|
| Tire Size | 18R33 (E-4) |
Engine
| Engine Model | 3408ETA |
|---|---|
| Displacement | 1,099 in³ |
| Gross Power | 510.0 hp |
| Net Power | 485.0 hp |
| Make | Cat |
Weights
| Operating Weight | 166,500 lb |
|---|---|
| Empty Weight | 76,611 lb |
| Loaded Weight | 166,890 lb |
| Weight Distribution Front - loaded | 33.3 % |
| Weight Distribution Rear - loaded | 66.7 % |
| Weight Distribution Front - empty | 49.8 % |
| Weight Distribution Rear - empty | 50.2 % |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Wheelbase | 146 in |
| Overall Length | 324 in |
| Overall Width | 145 in |
| Overall Height | 146 in |
| Dump Height | 305 in |
| Dump Ground Clearance | 19 in |
Transmission
| Max Speed | 35.5 mph |
|---|---|
| Number of Gears - Forward | 6 |
Drive System
| Drive Config | 4x2 |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 90,269.5 gal |
|---|
Articulating/Rigid
| Articulating/Rigid | Rigid |
|---|
Dump
| Rated Payload | 90,279 lb |
|---|---|
| Load Capacity - heaped | 35.99 yd³ |
| Load Capacity - Struck | 26.50 yd³ |
