Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Fuel Capacity | 185.0 gal |
|---|---|
| Tire Size | 21.00-35 32PR (E-3) |
| Engine Oil Capacity | 18.0 gal |
| Cooling System Fluid Capacity | 39.9 gal |
| Operating Voltage | 24 V |
| Steering System Fluid Capacity | 21.4 gal |
| Diff and Final Drive Fluid Capacity | 41.0 gal |
Engine
| Engine Model | 3412 |
|---|---|
| Displacement | 1,648 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 682.6 hp |
| Net Power | 650.4 hp |
| Aspiration | turbocharged and aftercooled |
| Torque Measured @ | — |
Weights
| Front Axle - empty | — |
|---|---|
| Empty Weight | 86,853 lb |
| Loaded Weight | 204,003 lb |
| Weight Distribution Front - loaded | 33.3 % |
| Weight Distribution Rear - loaded | 66.7 % |
| Weight Distribution Front - empty | 47.3 % |
| Weight Distribution Rear - empty | 52.7 % |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Wheelbase | 166 in |
| Overall Length | 366 in |
| Overall Width | 186 in |
| Overall Height | 167 in |
| Dump Height | 342 in |
| Dump Ground Clearance | 23 in |
Transmission
| Max Speed | 35.7 mph |
|---|---|
| Number of Gears - Forward | 7 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 118,987.0 gal |
|---|
Dump
| Dump Angle | 55 ° |
|---|---|
| Raise Time | 11.4 s |
| Lower Time | 14.2 s |
| Load Capacity - heaped | 44.69 yd³ |
| Load Capacity - Struck | 34.10 yd³ |
