Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
84 data points
Operating Specifications
| Fuel Capacity | 185.0 gal |
|---|---|
| Tire Size | 24.00R35 |
| Engine Oil Capacity | 20.1 gal |
| Cooling System Fluid Capacity | 36.2 gal |
| Operating Voltage | 24 V |
| Steering System Fluid Capacity | 9.0 gal |
| Diff and Final Drive Fluid Capacity | 37.0 gal |
| Brake/Hoist System Fluid Capacity | 35.2 gal |
| Top Speed - Loaded | 41.0 mph |
| Body Capacity - SAE 2:1 | 44.60 yd³ |
| Maximum Capacity | 96,260 lb |
| Nominal Payload Class (100%) | 96,260 lb |
| Lower Time | 12.5 s |
| Raise Time | 9.5 s |
| Body Capacity - Struck | 33.99 yd³ |
| Circle Clearance Diameter | 946 in |
Engine
| Engine Model | Cat 3412E TA-HEUI |
|---|---|
| Displacement | 1,648 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 682.6 hp |
| Net Power | 643.7 hp |
| Number of Cylinders | 12 |
| Max Torque | 1,707 lb-ft |
| Stroke | 6 in |
| Bore | 5 in |
| Gross Power - SAE J1995 | 650.0 hp |
| Net Power - ISO 9249 | 41.0 hp |
| Net Power - SAE J1349 | 53.6 hp |
| Flywheel Power | 650.0 hp |
| Net Power - 80/1269/EEC | 34.0 hp |
| Net Power - Cat | 650.0 hp |
Weights
| Operating Weight - Loaded | 204,000.00 lbs (92,532.96 kg) |
|---|---|
| Front Axle - empty | — |
| Rear Axle - empty | — |
| Front Axle - loaded | — |
| Rear Axle - loaded | — |
| Empty Weight | 87,083 lb |
| Loaded Weight | 219,007 lb |
| Weight Distribution Front - loaded | 33.3 % |
| Weight Distribution Rear - loaded | 66.7 % |
| Weight Distribution Front - empty | 47.3 % |
| Weight Distribution Rear - empty | 52.7 % |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Wheelbase | 166 in |
| Overall Length | 381 in |
| Overall Width | 176 in |
| Overall Height | 158 in |
| Dump Height | 347 in |
| Dump Ground Clearance | 28 in |
| Wheel Base | 166 in |
| Operating Width | 155 in |
| Overall Height - Body Raised | 348 in |
| Centerline Front Tire Width | 130 in |
| Loading Height - Empty | 150 in |
| Front Canopy Height | 175 in |
| Inside Body Length | 256 in |
Transmission
| Max Speed | 38.7 mph |
|---|---|
| Number of Gears - Forward | 7 |
| Number of Gears - Reverse | 1 |
| Forward - 1 | 6.3 mph |
| Forward - 2 | 8.6 mph |
| Forward - 3 | 11.7 mph |
| Forward - 4 | 15.6 mph |
| Forward - 5 | 21.2 mph |
| Forward - 6 | 28.6 mph |
| Forward - 7 | 40.9 mph |
| Reverse | 7.5 mph |
Tires & Wheels
| Standard Tire | 24.00R35 (E-4) |
|---|
Service Refill Capacities
| Cooling System | 39.9 gal |
|---|---|
| Fuel Tank | 185.0 gal |
| Steering System - Including Tank | 21.4 gal |
| Steering Tank | 14.6 gal |
| Brake Hoist System - Includes Tank | 103.9 gal |
| Torque Converter - Transmission System - Including Sump | 26.5 gal |
| Torque Converter - Brake - Hoist Hydraulic Tank | 58.2 gal |
Dump
| Raise Time | 9.5 s |
|---|---|
| Lower Time | 12.5 s |
| Load Capacity - heaped | 46.09 yd³ |
| Load Capacity - Struck | 34.80 yd³ |
Body Hoists
| Pump Flow - High Idle | 148.4 gal/min |
|---|---|
| Relief Valve Setting - Raise | 2,498 psi |
| Body Raise Time - High Idle | 9.5 s |
| Body Lower Time - Float | 12.5 s |
Final Drives
| Planetary Ratio | Planetary |
|---|
