Caterpillar
Terex
TA27
Off-Highway Truck
46 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Fuel Capacity | 250.2 gal |
|---|---|
| Tire Size | 24x49 42 PR |
Engine
| Engine Model | D348 |
|---|---|
| Displacement | 1,788 in³ |
| Gross Power | 870.0 hp |
Weights
| Empty Weight | 124,402 lb |
|---|---|
| Loaded Weight | 294,405 lb |
Dimensions
| Wheelbase | 180 in |
|---|---|
| Overall Length | 386 in |
| Overall Width | 139 in |
| Overall Height | 193 in |
| Dump Height | 367 in |
| Dump Ground Clearance | 163 in |
Transmission
| Max Speed | 36.3 mph |
|---|
General Specifications
| Operating Weight lbs (kg) | 363,000 (164,654) Starting 2024 Model Year |
|---|---|
| Engine type | Cat C32B Starting 2024 Model Year |
| Articulated/Rigid | Rigid Starting 2024 Model Year |
| Drive Configuration | 2WD Starting 2024 Model Year |
| Rated Payload Tons (Metric Tons) | 101.1 (91.7) Starting 2024 Model Year |
| Mfg. Model | 777 Starting 2024 Model Year |
| Planetary Powershift Transmission | Auto Starting 2024 Model Year |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 169,981.5 gal |
|---|
Dump
| Rated Payload | 170,000 lb |
|---|---|
| Load Capacity - heaped | 67.10 yd³ |
| Load Capacity - Struck | 47.49 yd³ |
