Caterpillar
BOMAG
BC 672 RB
Landfill Compactor
28 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 90,207 lb |
|---|---|
| Fuel Capacity | 206.6 gal |
| Hydraulic System Fluid Capacity | 30.9 gal |
| Cooling System Fluid Capacity | 30.6 gal |
| Transmission Fluid Capacity | 17.4 gal |
Engine
| Engine Model | Cat C15 ACERT |
|---|---|
| Displacement | 928 in³ |
| Gross Power | 435.0 hp |
| Net Power | 405.0 hp |
| Max Torque | 1,479 lb-ft |
| Stroke | 7 in |
| Bore | 5 in |
| Emissions | Tier 4 Final/Stage IV or Tier 3/Stage IIIA equivalent |
| High Idle Speed | 2,300 rpm |
| Low Idle Speed | 800 rpm |
Weights
| Operating Weight | 90,207 lb |
|---|
Hydraulic System
| Main Relief Pressure | 3,495 psi |
|---|---|
| Maximum Supply Pressure | 3,495 psi |
Dimensions
| Ground Clearance | 26 in |
|---|---|
| Height - Top of Cab | 180 in |
| Wheelbase | 146 in |
| Wheel Base | 146 in |
| Width Over Wheels | 150 in |
| Height - Top of Hood | 131 in |
| Ground Clearance - Bumper | 39 in |
| Height - Top of Exhaust Pipe | 175 in |
| Hitch to Centerline of Front Axle | 73 in |
| Height - ROPS/Canopy | 169 in |
| Height - Top of Cab with A/C | 180 in |
Transmission
| Number of Forward Gears | 3 |
|---|---|
| Number of Reverse Gears | 3 |
| Transmission Type | Planetary - Powershift - ECPC |
Brakes & Steering
| Parking brake | Drum and Shoe Spring Applied Hydraulic Released |
|---|
Service Refill Capacities
| Fuel Tank | 206.6 gal |
|---|---|
| Differential - Final Drives - Front | 26.4 gal |
| Differential - Final Drives - Rear | 29.1 gal |
| Transmission | 17.4 gal |
| Cooling System | 30.6 gal |
| Engine Crankcase | 9.0 gal |
| Hydraulic Tank Only | 35.4 gal |
Wheels
| Front Wheels Drum Diameter | 5 in |
|---|---|
| Front Wheels Drum Width | 4 in |
Axles
| Front | Planetary - Fixed |
|---|---|
| Rear | Planetary - Oscillating |
| Oscillation Angle | 5 ° |
Hydraulic System - Steering
| Steering System - Circuit | Double Acting - End Mounted |
|---|---|
| Steering System - Pump | Piston - Variable Displacement |
| Steering Pressure Limited | 3,481 psi |
| Bore | 5 in |
| Maximum System Flow | 170 L/min @ 1950 rpm (44.9 gal/min @ 1950 rpm) |
| Stroke | 23 in |
| Vehicle Articulation Angle | 86 ° |
