CaterpillarCaterpillar
826H
Landfill Compactor
46 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 118,348 lb |
|---|---|
| Fuel Capacity | 209.5 gal |
| Hydraulic System Fluid Capacity | 36.2 gal |
| Engine Oil Capacity | 15.9 gal |
| Cooling System Fluid Capacity | 28.3 gal |
| Transmission Fluid Capacity | 22.0 gal |
Engine
| Engine Model | C18 diesel with ACERT Technology |
|---|---|
| Displacement | 1,105 in³ |
| Gross Power | 523.0 hp |
| Net Power | 468.0 hp |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Height - Top of Cab | 165 in |
| Wheelbase | 180 in |
Transmission
| Max Speed | 6.8 mph |
|---|---|
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Blades
| Blade Width | 205 in |
|---|---|
| Blade Height | 88 in |
| Blade Capacity | 25.90 yd³ |
Wheels
| Front Wheels Drum Diameter | 68 in |
|---|---|
| Front Wheels Drum Width | 55 in |
| Rear Wheels Drum Diameter | 68 in |
| Rear Wheels Drum Width | 55 in |
