Caterpillar
Pel-Job
EL851
Wheel Loader
5 specifications
1 / 5
Image 1 of 5
Specifications
58 data points
Operating Specifications
| Operating Weight | 14,210 – 18,102 lb |
|---|---|
| Fuel Capacity | 29.9 gal |
| Tire Size | 15.5 x 25.8 PR |
| Hydraulic System Fluid Capacity | 15.1 gal |
| Static Tipping Weight | 9,877 lb |
| Operating Voltage | 12 V |
| Turning Radius | 186 in |
| Engine Oil Fluid Capacity | 3.0 gal |
| Rear Axle Oscillation | 22 ° |
| Alternator Supplied Amperage | 40 A |
| Front Axle/Diff Fluid Capacity | 4.0 gal |
| Rear Axle/Diff Fluid Capacity | 4.0 gal |
| Cooling System Fluid Capacity | 6.7 gal |
| Transmission Fluid Capacity | 6.1 gal |
Engine
| Engine Model | C3.6 |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 65.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Lower Time | 3.5 s |
| Dump Time | 1.3 s |
| Relief Valve Setting | 2,500 psi |
| Pump Type | double section gear |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 120 in |
| Wheelbase | 93 in |
| Width Over Tires | 80 in |
| Reach at Max Lift and Dump | 35 in |
| Length with Bucket on Ground | 216 in |
| Hinge Pin - Max Height | 122 in |
Transmission
| Max Speed - Forward | 15.0 mph |
|---|---|
| Max Speed - Reverse | 6.6 mph |
| Transmission Type | Planetary power shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 1 |
Bucket
| Bucket Capacity - heaped | 1.40 yd³ |
|---|---|
| Dump Clearance at Max Raise | 97 in |
| Breakout Force | 11,632 – 16,291 lb |
| Bucket Width | 85 in |
General Specifications
| Net Power | 110.00 hp (82.03 kw) Starting 2023 Model Year |
|---|---|
| Operating Weight | 17,822 (8,086) Starting 2024 Model Year |
| Operating Weight lbs (kg) | 17,822 (8,086) Starting 2025 Model Year |
| Bucket Capacity | 1.7 - 2.0 (1.3 - 1.50) Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 1.7 - 2.0 (1.3 - 1.50) Starting 2025 Model Year |
| Engine type | Cat C3.6 Starting 2024 Model Year |
| Engine Power | 110 (82) Starting 2024 Model Year |
| Max Dump Height | 8.80 ft (2.68 m) Starting 2021 Model Year |
| OperatingWeight lbs. (kg) | 17,822 (8,086) Starting 2026 Model Year |
| Travel Speed(Fwd/Rev) | 25 / 12.5 mph Starting 2025 Model Year |
| Engine Power Net hp (kW) | 110 (82) Starting 2025 Model Year |
| Tip Load | 10,785 (4,878) Starting 2024 Model Year |
| Engine | C3.6 Starting 2023 Model Year |
| Breakout Force | 13,577.00 lbs ft (18,407.70 nm) Starting 2023 Model Year |
| Full-Turn Tipping Load | 10,641.00 lbs (4,826.68 kg) Starting 2023 Model Year |
| Travel Speed | 25 / 12.5 mph Starting 2024 Model Year |
| Tip Load lbs. (kg) | 10,785 (4,878) Starting 2025 Model Year |
| Rated Bucket Capacity | 1.7 cu yd Starting 2021 Model Year |
