Caterpillar
Volvo
L45
Wheel Loader
45 specifications
Caterpillar
938G
- Operating Weight
- 29,059 lb
- Bucket Capacity - heaped
- 3.20 yd³
- Gross Power
- 145.0 hp
- Net Power
- 158.0 hp
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 29,059 lb |
|---|---|
| Fuel Capacity | 67.1 gal |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Static Tipping Weight | 23,186 lb |
Engine
| Engine Model | 3126DITA |
|---|---|
| Displacement | 439 in³ |
| Gross Power | 145.0 hp |
| Net Power | 158.0 hp |
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Lower Time | 2.8 s |
| Dump Time | 1.4 s |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 131 in |
| Width Over Tires | 103 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 289 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Max Speed - Reverse | 13.7 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 108 in |
| Breakout Force | 24,770 lb |
| Bucket Width | 107 in |
