Caterpillar
Kawasaki
70ZV-2
Wheel Loader
48 specifications
1 / 5
Image 1 of 5
Specifications
78 data points
Operating Specifications
| Operating Weight | 52,254 lb |
|---|---|
| Fuel Capacity | 100.4 gal |
| Tire Size | 25 |
| Hydraulic System Fluid Capacity | 29.0 gal |
| Static Tipping Weight | 38,354 lb |
| Operating Voltage | 24 V |
| Turning Radius | 291 in |
| Engine Oil Fluid Capacity | 9.3 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 80 A |
| Front Axle/Diff Fluid Capacity | 16.9 gal |
| Rear Axle/Diff Fluid Capacity | 16.9 gal |
| Cooling System Fluid Capacity | 10.3 gal |
| Transmission Fluid Capacity | 11.6 gal |
| Breakout Force | 38,984 lb |
Engine
| Engine Model | Cat C9.3 ACERT |
|---|---|
| Displacement | 568 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 286.0 hp |
| Net Power | 262.0 hp |
| Number of Cylinders | 6 |
| Aspiration | TURBOCHARGED |
| Torque Measured @ | 1,400 rpm |
| Stroke | 6 in |
| Bore | 5 in |
| Torque Rise | 38.0 % |
| Net Power - ISO 9249 | 267.0 hp |
| Maximum Net Power - 1,800 rpm - EEC 80/1269 - Metric | 271.0 hp |
| Peak Net Torque - 1,400 rpm - SAE J1349 | 940 lb-ft |
| Maximum Net Power - 1,800 rpm - EEC 80/1269 | 267.0 hp |
Weights
| Operating Weight | 53,311 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 80.6 gal/min |
|---|---|
| Raise Time | 5.9 s |
| Lower Time | 2.4 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 1,000 psi |
| Pump Type | PISTON |
| Hydraulic Cycle Time - Total | 9.8 s |
| Hydraulic Cycle Time - Lower, Empty, Float Down | 2.4 s |
| Steering System - Pump Type | Piston |
| Implement System - Maximum Operating Pressure | 4,496 psi |
| Hydraulic Cycle Time - Dump, at Maximum Raise | 1.5 s |
| Hydraulic Cycle Time - Raise from Carry Position | 5.9 s |
| Implement System - Optional 3rd Function Maximum Flow | 79.3 gal/min |
| Implement System - Optional 3rd Function Maximum Pressure | 3,000 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 142 in |
| Wheelbase | 135 in |
| Width Over Tires | 117 in |
| Length with Bucket on Ground | 349 in |
Transmission
| Max Speed - Forward | 23.2 mph |
|---|---|
| Max Speed - Reverse | 23.2 mph |
| Transmission Type | POWERSHIFT |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Forward - 1 | 4.2 mph |
| Reverse - 1 | 4.9 mph |
| Forward - 2 | 7.8 mph |
| Reverse - 2 | 8.5 mph |
| Forward - 3 | 13.9 mph |
| Reverse - 3 | 14.6 mph |
| Forward - 4 | 23.2 mph |
| Reverse - 4 | 23.9 mph |
Brakes & Steering
| Brakes | Meet OSHA SAE J1473 OCT90 and ISO 3450-1985 required standards |
|---|
Cab & Operator
| ROPS/FOPS | Meets SAE and ISO standards |
|---|
Tires & Wheels
| Tires | Choices |
|---|
Bucket
| Bucket Capacities | 11.99 yd³ |
|---|
Service Refill Capacities
| Cooling System | 17.2 gal |
|---|---|
| Transmission | 13.2 gal |
| Crankcase | 6.5 gal |
| Differential - Final Drives - Front | 16.9 gal |
| Differential - Final Drives - Rear | 16.9 gal |
| Hydraulic Tank | 52.3 gal |
| Fuel Tank - Standard | 101.0 gal |
Axles
| Front | Fixed |
|---|---|
| Rear | Oscillating ?13 degrees |
| Maximum Single-Wheel Rise and Fall | 20 in |
Sound
| Standards | Standards |
|---|
