CaterpillarCaterpillar
938G II
Wheel Loader
42 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 51,260 lb |
|---|---|
| Fuel Capacity | 99.6 gal |
| Tire Size | 26.5-R25 XHA (L-3) radial |
| Hydraulic System Fluid Capacity | 54.2 gal |
| Front Axle/Diff Fluid Capacity | 12.5 gal |
| Rear Axle/Diff Fluid Capacity | 12.5 gal |
| Cooling System Fluid Capacity | 12.0 gal |
| Transmission Fluid Capacity | 15.9 gal |
Engine
| Displacement | 641 in³ |
|---|---|
| Gross Power | 266.0 hp |
| Aspiration | Turbocharged |
| Stroke | 6 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 98.9 gal/min |
|---|---|
| Raise Time | 6.1 s |
| Lower Time | 2.1 s |
| Dump Time | 1.3 s |
| Relief Valve Setting | 3,000 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 135 in |
| Wheelbase | 132 in |
| Width Over Tires | 117 in |
| Reach at Max Lift and Dump | 54 in |
| Length with Bucket on Ground | 342 in |
| Hinge Pin - Max Height | 175 in |
Transmission
| Max Speed - Forward | 23.2 mph |
|---|---|
| Max Speed - Reverse | 26.5 mph |
| Transmission Type | Power shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 6.20 yd³ |
|---|---|
| Bucket Capacity - struck | 5.21 yd³ |
| Breakout Force | 36,405 lb |
| Bucket Width | 127 in |
