Caterpillar
John Deere
544
Wheel Loader
42 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 30,818 lb |
|---|---|
| Fuel Capacity | 67.1 gal |
| Tire Size | 20.5R25 |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Static Tipping Weight | 25,230 lb |
| Operating Voltage | 24 V |
| Turning Radius | 235 in |
| Engine Oil Fluid Capacity | 8.2 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 8.0 gal |
| Rear Axle/Diff Fluid Capacity | 8.5 gal |
| Cooling System Fluid Capacity | 12.7 gal |
| Transmission Fluid Capacity | 8.0 gal |
Engine
| Engine Model | 3126B HEUI |
|---|---|
| Displacement | 439 in³ |
| Gross Power | 179.7 hp |
| Aspiration | turbocharged |
| Torque Rise | 62.0 % |
Hydraulic System
| Pump Flow Capacity | 43.1 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 2.8 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 3,597 psi |
| Pump Type | vane type |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 131 in |
| Wheelbase | 120 in |
| Width Over Tires | 101 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 283 in |
| Hinge Pin - Max Height | 152 in |
Transmission
| Max Speed - Forward | 24.2 mph |
|---|---|
| Max Speed - Reverse | 14.5 mph |
| Transmission Type | electronic planetary powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.10 yd³ |
|---|---|
| Bucket Capacity - struck | 2.69 yd³ |
| Dump Clearance at Max Raise | 114 in |
| Breakout Force | 28,326 lb |
| Bucket Width | 107 in |
