CaterpillarCaterpillar
950F
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
56 data points
Operating Specifications
| Operating Weight | 57,770 lb |
|---|---|
| Fuel Capacity | 101.0 gal |
| Hydraulic System Fluid Capacity | 52.3 gal |
| Cooling System Fluid Capacity | 17.4 gal |
| Transmission Fluid Capacity | 13.2 gal |
| Breakout Force | 44,075 lb |
Engine
| Engine Model | Cat C9.3 ACERT |
|---|---|
| Gross Power | 322.0 hp |
| Net Power | 288.0 hp |
| Bore | 5 in |
| Stroke | 6 in |
| Net Power - ISO 9249 | 288.0 hp |
| Maximum Net Power - 1,800 rpm - EEC 80/1269 - Metric | 292.0 hp |
| Peak Net Torque - 1,400 rpm - SAE J1349 | 985 lb-ft |
| Maximum Net Power - 1,800 rpm - EEC 80/1269 | 288.0 hp |
Weights
| Operating Weight | 57,770 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 90.0 gal/min |
|---|---|
| Raise Time | 5.9 s |
| Dump Time | 2.0 s |
| Relief Valve Setting | 4,496 psi |
| Pump Type | PISTON |
| Hydraulic Cycle Time - Total | 10.3 s |
| Hydraulic Cycle Time - Lower, Empty, Float Down | 2.4 s |
| Steering System - Pump Type | Piston |
| Implement System - Maximum Operating Pressure | 4,496 psi |
| Hydraulic Cycle Time - Dump, at Maximum Raise | 2.0 s |
| Hydraulic Cycle Time - Raise from Carry Position | 5.9 s |
| Implement System - Optional 3rd Function Maximum Flow | 79.3 gal/min |
| Implement System - Optional 3rd Function Maximum Pressure | 3,000 psi |
Transmission
| Max Speed - Forward | 22.9 mph |
|---|---|
| Max Speed - Reverse | 26.2 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Forward - 1 | 4.4 mph |
| Reverse - 1 | 5.0 mph |
| Forward - 2 | 7.8 mph |
| Reverse - 2 | 8.9 mph |
| Forward - 3 | 13.3 mph |
| Reverse - 3 | 15.2 mph |
| Forward - 4 | 22.9 mph |
| Reverse - 4 | 26.2 mph |
Brakes & Steering
| Brakes | Meet OSHA SAE J1473 OCT90 and ISO 3450-1985 required standards |
|---|
Cab & Operator
| ROPS/FOPS | Meets SAE and ISO standards |
|---|
Tires & Wheels
| Tires | Choices |
|---|
Bucket
| Bucket Capacities | 13.00 yd³ |
|---|
Service Refill Capacities
| Cooling System | 17.4 gal |
|---|---|
| Transmission | 13.2 gal |
| Crankcase | 6.5 gal |
| Differential - Final Drives - Front | 16.9 gal |
| Differential - Final Drives - Rear | 16.9 gal |
| Hydraulic Tank | 52.3 gal |
| Fuel Tank - Standard | 101.0 gal |
Axles
| Front | Fixed |
|---|---|
| Rear | Oscillating ?13 degrees |
| Maximum Single-Wheel Rise and Fall | 20 in |
Sound
| Standards | Standards |
|---|
