Caterpillar
Dynapac
F5CS
Asphalt Paver
17 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/o Screed | 8,995 lb |
|---|---|
| Fuel Capacity | 10.6 gal |
| Hydraulic System Fluid Capacity | 20.1 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 2M40 |
|---|---|
| Displacement | 105 in³ |
| Power Measured @ | 3,000 rpm |
| Gross Power | 35.0 hp |
| Number of Cylinders | 2 |
Dimensions
| Length of Track on Ground | 30 in |
|---|---|
| Transport Width | 119 in |
| Transport Height | 86 in |
| Track Width | 15 in |
| Length w/o Screed | 97 in |
Hopper/Paver
| Paving Width - max | 145 in |
|---|---|
| Paving Speed - max | 2.0 mph |
| Travel Speed - max | 2.1 mph |
| Auger Diameter | 7 in |
