Svedala
Dynapac
F5CS
Asphalt Paver
17 specifications
Svedala
DF45C
- Operating Weight w/ Screed
- 11,023 lb
- Paving Width - max
- 122 in
- Gross Power
- 45.0 hp
- Length w/ Screed
- 168 in
.jpg)
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Operating Weight w/ Screed | 11,023 lb |
|---|---|
| Operating Voltage | 24 V |
Engine
| Engine Model | D 2011L3i |
|---|---|
| Power Measured @ | 2,500 rpm |
| Gross Power | 45.0 hp |
Dimensions
| Length of Track on Ground | 55 in |
|---|---|
| Transport Height | 74 in |
| Track Width | 47 in |
| Length w/ Screed | 168 in |
| Width w/ Hopper Open | 109 in |
Hopper/Paver
| Paving Width - max | 122 in |
|---|---|
| Paving Speed - max | 0.7 mph |
| Hopper Capacity | 3 lb |
| Travel Speed - max | 3.2 mph |
| Auger Diameter | 14 in |
| Paving Thickness - max | 8 in |
