BOMAG
Dynapac
F5CS
Asphalt Paver
17 specifications
BOMAG
4410
- Operating Weight w/ Screed
- 12,000 lb
- Paving Width - max
- 158 in
- Gross Power
- 56.1 hp
- Length w/ Screed
- 145 in
1 / 5
Image 1 of 5
Specifications
13 data points
Operating Specifications
| Operating Weight w/ Screed | 12,000 lb |
|---|---|
| Fuel Capacity | 15.1 gal |
| Hydraulic System Fluid Capacity | 20.0 gal |
| Cooling System Fluid Capacity | 3.1 gal |
Engine
| Gross Power | 56.1 hp |
|---|
Dimensions
| Transport Width | 103 in |
|---|---|
| Transport Height | 78 in |
| Track Width | 13 in |
| Length w/ Screed | 145 in |
Hopper/Paver
| Paving Width - max | 158 in |
|---|---|
| Paving Speed - max | 1.8 mph |
| Travel Speed - max | 3.7 mph |
| Paving Thickness - max | 6 in |
Comparable machines
Other asphalt pavers in a similar weight class.
