Caterpillar

CP433C

Padfoot Compactor

Operating Weight
15,238 lb
Max Speed
8.3 mph
Gross Power
105.0 hp
All padfoot compactors
Caterpillar CP433C Padfoot Compactor
1 / 5
Image 1 of 5
Image: easternsurplus.net

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight15,238 lb
Max Speed8.3 mph
Fuel Capacity44.2 gal
Operating Width75 in
Hydraulic System Fluid Capacity18.8 gal
Engine Oil Capacity1.8 gal

Engine

Engine specifications
Engine Model3054T
Displacement427 in³
Gross Power105.0 hp
MakeCaterpillar

Dimensions

Dimensions specifications
Ground Clearance15 in
Height - Top of Cab117 in
Wheelbase9 in
Width Over Tires72 in
Turning Radius - Inside118 in
Overall Length w/ Blade191 in

Tires & Wheels

Tires & Wheels specifications
Tires14.9x24-6 ply

Drum

Drum specifications
Vibration Frequency 130 vpm
Centrifugal Force - High28,000 lb
Drum Diameter48 in
Centrifugal Force - Low13,800 lb
Vibration Frequency1,800 vpm
