Caterpillar
Hamm
3410P
Padfoot Compactor
31 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 25,530 lb |
|---|---|
| Max Speed | 8.0 mph |
| Fuel Capacity | 67.1 gal |
| Hydraulic System Fluid Capacity | 34.9 gal |
| Engine Oil Capacity | 4.0 gal |
Engine
| Engine Model | 3116 |
|---|---|
| Displacement | 403 in³ |
| Gross Power | 145.0 hp |
Dimensions
| Height - Top of Cab | 119 in |
|---|---|
| Width Over Tires | 97 in |
| Overall Length w/ Blade | 207 in |
Tires & Wheels
| Tires | 23.1x26 |
|---|
Drum
| Drum Width | 84 in |
|---|---|
| Vibration Frequency 1 | 30 vpm |
| Centrifugal Force - High | 50,000 lb |
| Drum Diameter | 61 in |
| Centrifugal Force - Low | 35,000 lb |
Blades
| Blade Width | 108 in |
|---|
