Caterpillar
Hamm
3410P
Padfoot Compactor
31 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 25,728 lb |
|---|---|
| Max Speed | 8.0 mph |
| Fuel Capacity | 58.2 gal |
| Operating Width | 96 in |
| Hydraulic System Fluid Capacity | 29.1 gal |
| Engine Oil Capacity | 5.3 gal |
Engine
| Engine Model | 3116T |
|---|---|
| Displacement | 403 in³ |
| Gross Power | 145.0 hp |
| Make | Caterpillar |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 122 in |
| Wheelbase | 9 in |
| Width Over Tires | 91 in |
| Turning Radius - Inside | 154 in |
| Overall Length w/ Blade | 207 in |
Tires & Wheels
| Tires | 23.1 x 26 - 8ply |
|---|
Drum
| Vibration Frequency 1 | 30 vpm |
|---|---|
| Centrifugal Force - High | 53,000 lb |
| Drum Diameter | 61 in |
| Centrifugal Force - Low | 29,700 lb |
| Vibration Frequency | 1,800 vpm |
