Caterpillar
R2900G
- Operating Weight
- 148,611 lb
- Bucket Capacity - heaped
- 9.40 yd³
- Gross Power
- 430.0 hp
- Net Power
- 389.0 hp
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 148,611 lb |
|---|---|
| Fuel Capacity | 225.6 gal |
| Tire Size | 29.5 x 29 34 PLY STMS |
| Hydraulic System Fluid Capacity | 37.0 gal |
| Static Tipping Weight | 88,015 lb |
| Turning Radius | 289 in |
| Engine Oil Fluid Capacity | 9.0 gal |
| Rear Axle Oscillation | 16 ° |
| Front Axle/Diff Fluid Capacity | 31.4 gal |
| Rear Axle/Diff Fluid Capacity | 33.5 gal |
| Cooling System Fluid Capacity | 19.8 gal |
| Transmission Fluid Capacity | 16.4 gal |
Engine
| Engine Model | C15 ACERT |
|---|---|
| Displacement | 928 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 430.0 hp |
| Net Power | 389.0 hp |
Hydraulic System
| Raise Time | 9.2 s |
|---|---|
| Lower Time | 3.1 s |
| Dump Time | 3.4 s |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 114 in |
| Wheelbase | 150 in |
| Width Over Tires | 119 in |
| Reach at Max Lift and Dump | 66 in |
| Length with Bucket on Ground | 445 in |
| Hinge Pin - Max Height | 180 in |
Transmission
| Max Speed - Forward | 15.7 mph |
|---|---|
| Max Speed - Reverse | 16.4 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 9.40 yd³ |
|---|---|
| Dump Clearance at Max Raise | 114 in |
| Breakout Force | 60,298 lb |
| Bucket Width | 120 in |
