Daewoo
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 7,231 lb |
|---|---|
| Fuel Capacity | 11.3 gal |
| Hydraulic Pump Flow Capacity | 19.6 gal/min |
| Hydraulic System Fluid Capacity | 16.9 gal |
| Hydraulic System Relief Valve Pressure | 2,986 psi |
Engine
| Engine Model | 3LDI |
|---|---|
| Displacement | 91 in³ |
| Power Measured @ | 1,950 rpm |
| Net Power | 24.6 hp |
Dimensions
| Height - Top of Cab | 93 in |
|---|---|
| Length of Track on Ground | 66 in |
| Tail Swing Radius | 55 in |
| Width to Outside of Tracks | 61 in |
Undercarriage
| Track Gauge | 49 in |
|---|---|
| Max Travel Speed | 2.7 mph |
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 124 in |
|---|---|
| Max Loading Height | 137 in |
| Shipping Length of Unit | 198 in |
| Max Cutting Height | 196 in |
| Shipping Height of Unit | 93 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
