Doosan
Terex
TA27
Off-Highway Truck
46 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Fuel Capacity | 88.5 gal |
|---|---|
| Engine Oil Capacity | 8.8 gal |
| Cooling System Fluid Capacity | 11.9 gal |
| Operating Voltage | 24 V |
| Transmission Fluid Capacity | 19.9 gal |
Engine
| Engine Model | DC9 |
|---|---|
| Displacement | 568 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 370.0 hp |
| Net Power | 362.0 hp |
| Number of Cylinders | 5 |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 1,381 lb-ft |
| Make | Scania |
| Stroke | 6 in |
| Bore | 5 in |
Weights
| Operating Weight | 113,318 lb |
|---|---|
| Front Axle - empty | 26,310 lb |
| Rear Axle - empty | 25,278 lb |
| Front Axle - loaded | 31 lb |
| Rear Axle - loaded | 76,721 lb |
Dimensions
| Overall Length | 377 in |
|---|---|
| Overall Height | 141 in |
| Dump Ground Clearance | 25 in |
Transmission
| Max Speed | 34.2 mph |
|---|---|
| Number of Forward Gears | 8 |
| Number of Reverse Gears | 4 |
General Specifications
| Operating Weight lbs (kg) | 112,436 (51,000) Starting 2020 Model Year |
|---|---|
| Engine type | Scania DC9 Starting 2019 Model Year |
| Articulated/Rigid | A Starting 2019 Model Year |
| Drive Configuration | 6x6 Starting 2019 Model Year |
| Rated Payload Tons (Metric Tons) | 30 (28) Starting 2021 Model Year |
| Mfg. Model | DA30-5 Starting 2019 Model Year |
| Drive System Mech/Electr. | M Starting 2019 Model Year |
Drive System
| Drive Config | 6x6 |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 61,729 lb |
|---|---|
| Dump Angle | 70 ° |
