Doosan
Komatsu
PW95-1
Excavator
29 specifications
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Operating Weight | 32,783 lb |
|---|---|
| Fuel Capacity | 70.0 gal |
| Hydraulic System Fluid Capacity | 45.0 gal |
| Hydraulic System Relief Valve Pressure | 5 psi |
| Engine Oil Capacity | 2.1 gal |
| Cooling System Fluid Capacity | 6.6 gal |
| Swing Drive Fluid Capacity | 0.8 gal |
| DEF tank capacity | 5.0 gal |
| Hydraulic Tank | 39.7 gal |
Engine
| Engine Model | 1204F |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 115.0 hp |
| Net Power | 113.0 hp |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 1,301 lb-ft |
| Engine Make | Perkins |
| Bore | 4 in |
| Stroke | 5 in |
| Air cleaner | Double Elements |
| Starter | 6.0 hp |
Weights
| Counterweight | 4,850 lb |
|---|
Hydraulic System
| Pilotpump-Gear Design | 7.9 gal/min |
|---|---|
| Relief Pressure - Boost | 4,694 psi |
| Relief Pressure -Normal | 4,978 psi |
Dimensions
| Tail Swing Radius | 88 in |
|---|---|
| Counterweight Clearance | 36 in |
| Undercarriage Width | 101 in |
| Track Shoe Width | 24 in |
Undercarriage
| Number of Shoes per Side | 46 |
|---|---|
| Number of bottom rollers per side | 7 |
| Number of top rollers per side | 1 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 243 in |
|---|---|
| Max Reach Along Ground | 335 in |
| Max Loading Height | 254 in |
| Max Vertical Wall Digging Depth | 185 in |
| Shipping Length of Unit | 301 in |
| Shipping Height of Unit | 121 in |
| Minimum swing radius | 103 in |
| Max Digging Reach | 341 in |
| Max Digging Height | 344 in |
| Min Digging Reach | 9 in |
Bucket
| Maximum Bucket Capacity | 0.60 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Electrical System
| Alternator | — |
|---|---|
| Battery | 12V 100AH |
| Starter | 24V |
Performance
| Maximum Grade | 70.0 % |
|---|---|
| Swing - Normal Mode | 4,694 psi |
| Swing-Power Mode | 4,978 psi |
| Traction Force -Draw bar Pull | 35,935 lb-ft |
| Travel-Normal Mode | 4,694 psi |
| Travel-Power Mode | 4,978 psi |
