Doosan
John Deere
2154D Butt TOP
Log Loader
Specifications pending
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Fuel Capacity | 132.1 gal |
|---|---|
| Hydraulic System Fluid Capacity | 126.9 gal |
| Operating Voltage | 24 V |
| Cooling System Fluid Capacity | 9.3 gal |
| Engine Oil Capacity | 9.6 gal |
Engine
| Engine Model | DL08 |
|---|---|
| Displacement | 466 in³ |
| Power Measured @ | 1,900 rpm |
| Number of Cylinders | 6 |
| Aspiration | turbocharged with air to air intercooler |
| Torque Measured @ | 1,300 rpm |
| Net Torque | 673 lb-ft |
Hydraulic System
| Pump Type | axial piston |
|---|---|
| Pump Flow Capacity | 130.0 gal/min |
| Relief Valve Pressure | 4,699 psi |
Dimensions
| Ground Clearance | 31 in |
|---|---|
| Overall Width | 143 in |
| Length of Track on Ground | 194 in |
| Tail Swing Radius | 126 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Shoe Size | 28 in |
| Max Speed | 2.9 mph |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Log Loader Option 1
| Max Lift Capacity Over Front at Ground Level | 28,570 lb |
|---|---|
| Max Height | 535 in |
| Shipping Height | 183 in |
| Boom/Stick Option (LGL) 1 | Boom 20'8 (6300mm)/Stick 12'10 (3910mm) |
| Max Depth Below Ground | 148 in |
